AHRI# 214377790
Capacity 48K
Indoor-1 IDUMSEPB-09HRFN1-MY5W(GA)*4
Indoor-2 +IDUMSEPB-12HRFN1-MW5W(GA)*1
Outdoor ODUM5OG-48HFN1-M-[X]
Power supply V-Ph-Hz 208/230V,1Ph，60Hz
Power supply SEER2 V 187-253
Cooling (Standard conditions)
Capacity (range) Btu/hr 48000(19300~51000)
Input W 4190(685~4700)
Current A 18.0(5.1~20.7)
EER2 Btu/hr/W 11.7
SEER2 Btu/hr/W 21.8
Heating (Standard conditions)
Capacity (range) Btu/hr 49000(11500~58000)
Input W 3780(710~5800)
Current A 17.8(5.3~25.5)
COP W/W 3.8
HSPF4 Btu/hr/W 9.8
HSPF5 Btu/hr/W 7.6
MINIMUM CIRCUIT AMPACITY A 42
Outdoor air flow A 50
Outdoor air flow CFM 4500
Outdoor noise level dB(A) 65
Outdoor unit
Dimension (W*D*H) mm 952x415x1333
Dimension (W*D*H) inch 37.48×16.34×52.48
Packing (W*D*H) mm 1095x495x1480
Packing (W*D*H) inch 43.11×19.49×58.27
Net/Gross weight kg 108.1/122.4
Net/Gross weight lb 238.32/269.84
Refrigerant type R410A
Minimum Outdoor Heating Temperature
℃ -30
℉ -22
