With the Pro-Series Wall Thermostats, contractors can offer owners easy, yet powerful and reliable control.
Attribute
Series Application: Multi-Stage 2 Heat / 1 Cool Programmable
Factory Part Number: RS9210
UPC: 662013227224
Dimensions: 4.7 x3.8 x 1in (119.6 x 97.6 x 26mm)
Mounting Type: Wall or junction box
System Fuel Source: Gas, electric or oil
Heat Pump Compatibility: Systems without auxiliary or emergency heatMillivolt Application Compatibility: Yes
Temperature Range: 41 °F to 95 °F (5 °C to 35 °C)
Control Temperature: 44 °F to 90 °F (7 °C to 32 °C)
Display Accuracy: +- 1 °F (at 68 °F) / +- 1 °C (at 20 °C)
Power Source: 24V AC (18 to 30V AC), 50/60 Hz for hardwire common wire or 2 AAA 1.5V alkaline batteries (included)
Terminals: Rh, Rc, C, Y, W, G, O, B
Features and Benefits
Two-stage heating and one-stage cooling control in a simple, modern design.
Quick, easy installation
Large, easy-to-read 4.6-square-inch blue backlit display
7-day, 5-1-1 or non-programmable
Heat pump-compatible: auxiliary/emergency heat
Filter change reminder (selectable on/off)
Adjustable temperature differential (swing)
Modern, user-friendly design and operation
