1 Heat / 1 Cool. Gas/Electric/HP
Selectable Fahrenheit or Celsius Display
5-1-1 Day Programmable
Manual (non-programmable) operation
4 Events / Day
Temporary Override with Override Icon on Display
Fan selector for automatic or continuous fan operation
Adjustable temperature differential
Compressor short cycle protection – Reduces wear and tear on HVAC equipment compressor
Worry free memory retention – Maintains programmed parameters even during power outages
HVAC equipment control using dry contact relays
Quick wire terminal block – uses sturdy wire clamps.
Attribute
Electrical Power: 3 VDC (2x AAA alkaline batteries)
Battery Life: 1 Year (Approximate)
Relay Voltage: 24 VAC / 50/60 Hz
Relay Contact Current: 1 Amp Max (inductive)
Control Range: Heating 40 to 90 °F (5 to 32 °C ) in 1 degree steps Cooling 60-95 °F (16 to 35 °C) in 1 degree steps
Control Accuracy: +/-1 °F @68 °F (0.5 °C @20 °C)
1st Stage Difference: +1/-1 °F (0.5 °C) or +/-2 °F(1 °C)
Dimensions : 3.35″Hx4.5″Wx1″D (85mm 114mmx102mmx26mm)
