AHRI# 213062284

Capacity: 30K
Indoor: AZPN/B36WAC
Outdoor: AZPN/30WD
Power supply (Outdoor): V- Ph-Hz, 208/230V,1Ph，60Hz

Cooling (Standard conditions)

Capacity (range) Btu/hr           30000(9900~35000)
Input – W:         2855(660~3720)
Current – A:     11.1(3.10~14.4)
EER2 – Btu/hr/W:          10.5
SEER2 Btu/hr/W:          15.5

Heating (Standard conditions)

 Capacity (range) – Btu/hr:       33000(9000~37000)
Input – W:         2845(640~3300)
Current – A:     11.0(3.00~13)
COP – W/W:  3.4
HSPF4 – Btu/hr/W:      9.7
HSPF5 – Btu/hr/W:      7.7
Throttle type:  TXV

Indoor unit

Dimension (W*D*H)  mm       533x533x609
Dimension (W*D*H)  inch       20.98×20.98×23.98
Packing (W*D*H)         mm       610x665x670
Packing (W*D*H)         inch      24.02×26.18×26.38
Net/Gross weight        kg           30.2/35
Net/Gross weight        lb            66.58/77.16
19.56(3.78~26.52)ise level    dB(A)   62

MINIMUM CIRCUIT AMPACITY (Outdoor): 23Amp
Throttle type : EXV
Outdoor unit

Dimension (W*D*H)  mm       946x410x810
Dimension (W*D*H)  inch      37.24×16.14×31.89
Packing (W*D*H)         mm       1090x500x885
Packing (W*D*H)         inch      42.91×19.69×34.84
Net/Gross weight        kg           72.5/77
Net/Gross weight        lb            159.83/169.75
Refrigerant type            R410A
