ElectricalThermostatThermostat Wire LVT 18-4

SKU: N/A

Cust Name

NCS INT’L MIS

CUST PART

39AA1804-1

TYPE

LVT NIPLL FT4 60C

AWG/COND

18 (1B) – 4

COLOUR

BROWN

LENGTH

75M

Description

FAS/LVT, 18/4 gauge, 75-m spool, brown. CSA, 300 V. PVC jacket.

Applications: For use in class 2 circuits, in exposed or concealed wiring or use in raceways, in dry or damp locations, fire alarms, thermostat controls, heating and air conditioning installations, burglar alarms, intercom systems, door bells, and other low voltage installations in accordance
with the rules of the Canadian Electrical Code, Part I.

LVT 60C, 30V
Conductors: 18 AWG solid bare copper.
Insulation: Polyvinyl chloride (PVC)
Voltage Rating: 30V
Temperature Rating: -15°C* to 60°C
Flame Rating: FT4
Standards: CSA C22.2 No. 35
